10.1 inch TFT LCD Module

EDL 10.1 inch TFT LCD module is a display panel that uses thin-film transistor (TFT) technology to produce high-quality color images. It is commonly used in electronic devices such as tablets, digital cameras, and portable game consoles. The display has a diagonal size of 10.1 inches and features a resolution of typically 1280 x 800 pixels or higher. The module usually includes a backlighting system and a touch screen digitizer, allowing users to interact with the device using touch controls.

LCD Size: 10.1 inch TFT

Resolution: 1024x600 pixel

Display Mode: TN/normally black

Viewing Direction: 6/12 clock, IPS full view

Interface: MIPI/LVDS/DSI

Module Size: 228.6(W)x143(H)x2.6(T)mm

Active Area: 135.36(H)x216.576(V)mm

Driver IC: FL7703 or equal

Driver Method: A-Si TFT active matrix

TP (optional): RTP, CTP

Working temperature: -20~70C

Storage temperature: -30~80C

The 10.1 inch TFT LCD module is a type of display screen that measures 10.1 inches diagonally across. Some features of this module may include a resolution of up to 1280x800 pixels, a high contrast ratio for clear and vivid images, and a wide viewing angle for easy visibility from different angles. It may also have a responsive touch screen and efficient power consumption to help conserve battery life in devices such as tablets or handheld gaming systems.
